GYS 050587 X6 Arm Set | 2 Copper Offset Arms, 220 mm, with Type A Caps
GYS X6 Arm Set
2 Copper Offset Arms (220 mm) + 2 Type A Caps
A matched pair of 220 mm OFFSET copper arms with Type A caps for liquid-cooled X-clamp spot welding. Offset reach gets the electrode into difficult, obstructed areas.
LENGTH: 220 mm FORCE: 400 daN @ 8 bar INCLUDES: 2 Type A caps
Genuine GYS consumable — supported by CRTE.
Choose Quantity
GYS X6 Arm Set — 2 Copper Offset Arms (220 mm)
Offset copper arm pair with Type A caps for liquid-cooled X-clamp spot welding.
This set gives you two 220 mm offset copper welding arms with two Type A caps. The offset shape reaches around flanges and obstructions to place welds where a straight arm can't, on the liquid-cooled X-clamp.
Why Shops Add the X6 Arm Set
- Offset geometry for difficult, obstructed access.
- 220 mm reach with efficient copper arms.
- Ships as a matched pair with 2 Type A caps.
Technical Details
| Arm length | 220 mm |
| Clamping force | 400 daN @ 8 bar |
| Material | Copper, offset geometry |
| Included | 2 arms + 2 Type A caps |
Compatibility
For the liquid-cooled X-clamp on GYSPOT BP.LX and BP.LCX; also fits the X-clamp of the air-cooled 100R and 32D machines.
